Which scene is running at the moment? A quick glaze at the lower display helps you. It is lit up in red and important for live operation. The upper display, which is lit up in blue, is used for programming.
Dim via pedals for the first time
Control brightness and fading via two big pedals on the bar. This way, you can work more intuitively and carefully than with the conventional buttons: More gentle fading is possible.
Discover the intelligent program selection
A big drawback of foot controllers has been the program selection until now. Usually, you had to go through the list of programs – and each program would start immediately. Bigfoot lets you pre-select the program. And the program will then only be started when you press the GO button. So you can select the next program unhurriedly.
Functions freely patchable – make it your way
With your brightness control, you don't neccesarily need to control the whole light set. You can adjust the system just as you like it. Choose only the front light, the blinders or a strobe for example, while the moving heads still draw their bright circles irrespectively of the dimmer. Provide a better overview by naming all chases individually.
Control the speed and more
Let the rhythm of the light movement be controlled by sound or set it via Tap button. Just tap the button twice in the rhythm you want and the system will adapt the beat. Double the speed or slow it down with the simple push of a button, when neccessary.
Kick it – it can take it
A foot controller must be able to stand heavy usage. That's no problem for Bigfoot: All used materials are of extremly durable material. The housing is made of solid metal. The big handle not only makes it easier for you to carry the device, it also protects the potentiometers from too many foot prints.
A full-fledged DMX light controller in a foot bar, with FX generator
- Fully programmable DMX foot controller for DMX light effect units such as moving heads, scanners and LED spot lights with RGBW color mixture
- 192 DMX channels can be assigned and inverted as desired to 16 control channels (softpatch)
- For 12 fixtures with max. 16 control channels each
- USB port for storing program data
- Quick programming thanks to the integrated FX generator with movement patterns and color effects
- Several effects can be used simultaneously
- 15 programmable chases with a total of 100 steps can be stored
- Programs can be freely named
- Simply preselect the desired program and trigger it with GO
- Beat control via music signal or TAP button
- Convenient control of dimmer, fade time and other functions by foot
- 8 encoders on 2 levels for adjusting DMX values
- Blackout function
- 2 x backlit LCD (2 x 16 characters each)
- 3-pin XLR connector
- Firmware update via USB
- Solid metal housing with handle
- Programmable 15 sequencens each with 100 scenes
- Can transmit up to 192 DMX channels
- Controlling by DMX; Sound to light via Microphone; Sound to light via RCA (f) mounting version
- Non-slip pedal housing
| Power supply: |
100-240 V AC, 50/60 Hz
9 V DC 800 mA |
| Power consumption: |
10 W |
| IP classification: |
IP20 |
| Protection class: |
Class III |
| Programs: |
Programmable
15 Sequences
Each with 100 Scenes |
| DMX channels: |
Output 192 |
| DMX output: |
1 x 3-pin XLR (F) mounting version |
| Power connection: |
Mains input Coaxial power connector (M) Power supply cord with AC adapter (provided) |
| Control: |
DMX; Sound to light via Microphone; Sound to light via RCA (f) mounting version |
| Housing color: |
Black |
| Display type: |
Monochrome LCD display |
| Available storage media: |
USB devices (FAT 32) |
| USB port: |
Typ A |
| Color: |
Black |
| Housing design: |
Non-slip pedal housing |
| Dimension: |
Width: 45 cm
Depth: 24 cm
Height: 10 cm |
| Weight: |
4.52 kg |
